GEMINI DRY
Dry concrete batching plant perfect for large construction sites
Dry concrete batching plant perfect for large construction sites. It is fitted with 5 aggregate storage bins. Production 120 m³/h.
In this type of plant: water, aggregates, cement and additives are accurately and continuously batched and then separately loaded (in a predetermined sequence) directly onto the truck mixer.
Each MEV plant can be customized according to specific customer requirements.
| Specifications | |
|---|---|
| GEMINI S5 - D120 | |
| Production | 120 m³/h |
| Aggregate storage bins | 5 |
| Aggregates hopper capacity | 100 m³ |
| Outfeed conveyor | 2x5,5m |
| Conveyor for truck mixer loading | 1x16m |
| Aggregate weighing | 20.000 Kg |
| Cement weighing | 5.000 Kg |
| Screw conveyor diameter | 273 mm |
| Silos | 2÷3 |
| Silos capacity | 50÷100 tonn. |
| Automatic handling | Electromechanical or fully computerized |
